Camera
Image Sensor 3K CMOS
Signal System PAL/NTSC
Resolution 2960 (H) × 1665 (V)
Frame Rate TVI: 3K @20 fps, 4 MP @25 fps/30 fps, 1080p @25 fps/30 fps
AHD: 5 MP @20 fps, 4 MP @25 fps/30 fps
CVI: 4 MP @25 fps/30 fps
CVBS: PAL/NTSC
Min. Illumination 0.001 Lux @(F1.0, AGC ON), 0 Lux with white light
Shutter Time PAL: 1/25 s to 1/50,000 s;NTSC: 1/30 s to 1/50,000 s
Lens 2.8 mm, 3.6 mm fixed focal lens
Field of View 2.8 mm, horizontal FOV: 105°, vertical FOV: 60°, diagonal FOV: 143°
3.6 mm, horizontal FOV: 80°, vertical FOV: 50°, diagonal FOV: 112°
Lens Mount M12
Light Alarm Solid Light Alarm (White Light)
Day & Night ICR
WDR (Wide Dynamic Range) Digital WDR
Angle Adjustment Pan: 0° to 360°, Tilt: 0° to 90°, Rotation: 0° to 360°
Microphone
Pickup Distance In a radius of up to 5 m
Amount 1
Illuminator
Supplement Light Type Smart,IR,White Light
Supplement Light Range IR: Up to 20 m,White Light: Up to 20 m
Day/Night Mode Auto/Color
White Light Auto/Off
Image Mode STD/HIGH-SAT/HIGHLIGHT
AGC Yes
White Balance Auto/Outdoor/Global/Manual
AE (Auto Exposure) Mode HLS;DWDR;BLC;HLC;Global
Noise Reduction 2D DNR
Language English
Function Smart IR;Brightness;Sharpness;AGC;Anti-Banding
Interface
Video Output Switchable TVI/AHD/CVI/CVBS
Audio In Built-in mic
General
Power 12 VDC ± 25%, max.3.9 W,*You are recommended to use
one power adapter to supply the power for one camera
Operating Conditions -40 °C to 60 °C (-40 °F to 140 °F), Humidity: 90% or less
(non-condensing)
Protection Leve lIP67
Material Plastic
Communication HIKVISION-C
Dimension 161.1 mm × 70 mm × 70 mm (6.34″ × 2.76″ × 2.76″)
Weight Approx. 230 g (0.51 lb.)
